Armadillo Green

Turn waste into products with Armadillo Green. This 3D bioprinter enables you to print sawdust and other natural biomaterials in any shape. Armadillo Green was designed for use with our food safe Bio Binder and offers a waste-free production process.

Sustainable production reinvented

Armadillo Green is a 3D bioprinter designed to print environmentally friendly, natural materials. It was designed for CONCR3DE’s unique biodegradable Bio Binder to print with all kinds of sawdust - even the sawdust from your own workshop or factory. With the Armadillo Green printer you can give your bio-based waste materials a second life in an entirely new shape.

From waste to riches

Material Options
Armadillo Green and our proprietary Bio Binder can be used to created all kinds of products. Think of applications like furniture, home decor, interior design and more. But that’s not all - Bio Binder can even be used to create custom water soluble tooling and molds.
Bio Binder
CONCR3DE’s Bio Binder is an environmentally friendly material that is food safe and fully biodegradable. By using a naturally occuring polyme, Bio Binder enables printing any powder-based biomaterial with our Armadillo Green printer.

Ready for serial production

Integrated NOAH control
Armadillo Green is conveniently operated using our NOAH software. Running on integrated, optimize hardware and featuring an intuitive user interface, NOAH offers full access to all parameters of the printing process and any add-ons installed on the printer.
Depowdering Station (optional)
Our Depowdering Station offers a clean chamber to easily depowder prints, with a rotating platform to reach in the tiniest nooks and crannies. Its integrated air compressor and industrial vacuum remove even the finest of powder residue, speeding up the depowdering process and keeping your infrastructure clean.
Extra Large (Optional)
Our Depowdering Station offers a clean chamber to easily depowder prints, with a rotating platform to reach in the tiniest nooks and crannies. Its integrated air compressor and industrial vacuum remove even the finest of powder residue, speeding up the depowdering process and keeping your infrastructure clean.

Related items

Upcycling
CONCR3DE is dedicated to upcycling waste materials, whether bio-based or stone. You can now create value, in the form of sustainable, functional printed end-use products, from material streams that were previously deemed worthless - or even expensive to dispose of.
Read more
Bio & Sustainable
At CONCR3DE, sustainability and the reduction or even upcycling of waste are core values. Our range of Bio & Sustainable allows you to take natural (waste) streams and create value using non-toxic binders and sustainable, recyclable powder options.
Read more
Technology
Binder jetting 3D printing is based on two key elements: a powder and a binder. The powder can be a concrete, metal, ceramic, or other material you want to bond in powder form. The binder is a liquid, which acts as an adhesive between powder layers.
Read more
Publications
Find a wealth of additional resources in our publications section! Explore how binder jetting additive manufacturing achieves sustainability benefits and waste reductions, which leads to interesting business cases and a net positive result for our planet.
Read more

Partners

Technical specifications

Armadillo Green Armadillo Green XL
Print box dimensions 370 x 260 x 250 mm 440 x 440 x 250 mm
Capacity 48 liters/day 96 liters/day
Printhead precision 400 DPI 400 DPI
Layer height 300 µm 300 µm
Powder compatibility PB & PF range powders PB & PF range powders
Binder compatibility BB range binders BB range binders
Connectivity Ethernet (cable included) Ethernet (cable included)
Power requirements 2 x 230 V 2 x 230 V
Dimensions 1.600 x 1.100 x 1.600 mm 2.300 x 1.250 x 1.900 mm
Space requirements 2.400 x 2.000 x 2.200 mm 3.100 x 2.200 x 2.500 mm
Weight 600 kg 650 kg
Software NOAH Production (included) NOAH Production (included)
Specifications
Download PDF
Our experts will gladly advise you on the available options.

Learn more
